北米Model "A2600BE-B" EDITED: 2020/ 10/ 1
& To Install the Cover Housing
s06ak05
1. Insert the left side cover housing end
into the retainer, then insert the right cover
housing end into the right retainer.
Make sure both ends are clicked into the
retainers.
NOTE
If the label on the cover housing is
placed on the top, the cover housing
will be installed in reverse and it will not
be affixed to the vehicle body.
2. Align the right side of the front cover
rod end with a triangle mark on the cargo
area trim.
NOTE
When the rear seatbacks are reclined,
align the front cover rod to the rear
triangle mark.
3. Push the front cover rod on the right
side against the cargo area trim to shorten
the front cover rod.
4. Once the right side is aligned, align the
left side to a triangle mark on the cargo
area trim to fix the front cover in place.
CAUTION
When reclining the rear seatback,
move the front cover backward so
that the cover is not damaged
& Using the Cover
s06ak01
WARNING
Do not place anything on the ex-
tended cover. Putting excessive
weight on the extended cover can
break it and the object on the cover
could tumble forward in the event of
a sudden stop or collision. This
could cause serious injury.
CAUTION
Be careful not to scratch the rear
gate stays while extending and re-
winding the cover. Scratches on the
stays could cause leakage of gas
from the stays, which may result in
their inability to hold the rear gate
open.
– CONTINUED –
Lifting Cargo Cover (Outback – If Equipped)
315
6
Interior Equipment
