北米Model "A2600BE-B" EDITED: 2020/ 10/ 1
& How to Access the Front View
Monitor
s07bq01
1) Front view monitor switch
To change over to the camera screen,
make sure the ignition switch is in the “ON”
position, then press the front view monitor
switch under the following conditions.
. The vehicle speed is below 12 mph (20
km/h).
. The select lever is in except “R”.
NOTE
The screen will change over to the rear
view image when the select lever is
moved to “R”. Refer to “Rear View
Camera” FP379.
& How to Cancel the Front View
Monitor
s07bq02
! Manual cancellation
s07bq0201
The Front View Monitor will be canceled by
either of the following operations.
. Press the front view monitor switch
again.
. Touch
(car settings icon).
. Touch
(HOME).
. Touch
(driver profiles icon).
! Automatic cancellation
s07bq0202
If any of the following conditions are met,
the Front View Monitor is canceled auto-
matically.
After accessing the Front View Monitor
by pressing the front view monitor
switch:
. Approximately 3 minutes have passed
since the last operation.
. The vehicle speed becomes 12.5 mph
(20 km/h) or higher.
. The select lever is shifted to the “P”
position.
. Pulling up the parking brake switch with
the brake pedal depressed to apply the
parking brake.
& Range of Image on Screen
s07bq03
A) Traffic intersection with a poor visibility
view
B) Parking facing a wall
1) Range of displayed image
2) Obstacles (e.g., buildings, fences or
other vehicles)
– CONTINUED –
Front View Monitor
377
7
Starting and Operating
To Next Page
