Rear
Window
Wiper
Blade
Assembly
(Outback)
s1
1az03
1.
Raise
the
wiper
arm
off
the
rear
window
.
2.
Turn
the
wiper
blade
assembly
coun-
terclockwise.
3.
Pull
the
wiper
blade
assembly
toward
you
to
remove
it
from
the
wiper
arm.
&
Rear
Window
Wiper
Blade
Rubber
(Outback)
s1
1az04
1.
Pull
out
the
end
of
the
blade
rubber
assembly
to
unlock
it
from
the
plastic
support.
Replacement
of
Wiper
Blades
514
519
521
