Appendix
10.1 Technical Data
Communication
Max. number of devices 30 at most*
Communication ports
RS485 interface 3
Ethernet
1 x RJ45, 10/100/1000Mbps
Digital input 5, Max. 24VDC
Analog input 4, support 4～20mA or 0～10VDC
Wireless Communication
4G Communication
LTE(FDD): B1, B3, B5, B8
LTE(TDD): B38,B39, B40, B41
TD-SCDMA: B34, B39
CDMA: BC0
GSM: 900/1800 MHz
WCDMA: B1, B8
WLAN communication
802.11 b/g/n/ac; HT20/40/80MHz; 2.4GHz/
5GHz
Power Supply
DC input 24VDC, max. current: 1.2A
DC output 24VDC, 0.5A
Power consumption <10W
Ambient Conditions
Operating temperature -30℃ ~ +60℃
Storage temperature -40℃ ~ +70℃
Relative air humidity ≤95% (no condensation)
Elevation ≤4000m
Protection class IP20
Mechanical Parameters
Dimensions (W x H x D) 200 x 110 x 60 mm
Weight 500 g
Mounting type Top-hat rail mounting/ wall mounting
