Sungrow Logger1000A User Manual

63
Step 2 If auto IP allocation is , it is recommended to obtain the current IP address of the ETH
port by connecting the WLAN module and logging into 11.11.11.1.
Step 3 If the parameter Automatically obtain IP settings (DHCP) is set to
fill in the informa-
tion such as the IP Address, Subnet Mask, and Default Gateway, and click the button
to save the operation.
- - End
The default IP address of the ETH port is 12.12.12.12.
If both auto IP allocation and WLAN STA client are enabled, ensure that the Ether-
net and the WLAN STA are at different network segment. Otherwise, it is probably
that neither of the two networks is available.
7.10.11.4 Mobile network
Perform Mobile network setting on this interface.
Step 1 Click “System→Port Parameter→Mobile Network” to enter the corresponding interface.
Step 2 After modifying the APN, Username and Password, click
to save the information.
- - End
7.10.11.5 WiFi
Perform WiFi setting on this interface.
Client
Client refers to a case in which the Logger1000 connect to another hotspot or router via the
WLAN function.
Click “System→Port Parameter→WiFi” to enter the corresponding interface. Users will en-
ter the client mode by default, and the WLAN switch is turned on.
Hotspot
Hotspot mode means that the Logger1000 is used as an hotspot, and the PC or mobile
phone can be connected to the Logger1000 via the WLAN function.
Click “System→Port Parameter→WiFi” to enter the corresponding interface. Click Hot-
spotto enter the corresponding interface.
User Manual 7 WEB Interface
