60
10 Operation of LCD Display
10.1 Description of Button Function
Inverter offers two buttons for user to look up the running information and
configure parameters. The two buttons have multiple functions. Please refer to Tab.
10-1 before any operation onto inverter.
Tab. 10-1 Button function
Button Operation Description
Press for less
than 2 seconds
Move upwards or downwards or scroll among set
values. Hereinafter, it is referred to as “Press ”.
Press for more
than two
seconds
Return to the previous menu or cancel the command.
Hereinafter, it is referred to as “Press ESC”.
Press for less
than 2 seconds
Move left or right, or turn pages. Hereinafter, it is
referred to as “Press ”.
Press for more
than two
seconds
Enter into the sub-menu or confirm the command.
Hereinafter, it is referred to as “Press ENTER”.
If there is no button operation for:
1 minute, LCD backlight is OFF;
2 minutes, system returns to the default menu (main screen).
