6-42 POWER UNIT

11. Remove two compression rings (top and 2nd) and oil ring

from piston.

12. Mark cylinder number on conrod using quick dry paint.

13. Remove piston pin circlips as shown.

14. Remove piston pin from conrod.

NOTE:

Reassemble each piston, piston pin and conrod in their origi-

nal combination and position.

1. Piston pin circlip

Questions and Answers:

Need help?

Do you have a question about the Suzuki DF 90 and is the answer not in the manual?

Suzuki DF 90 Specifications

General

Steering	Remote
Starting System	Electric
Number of Cylinders	4
Trim Method	Power Trim and Tilt
Full Throttle Operating Range	5, 500 - 6, 300 rpm
Fuel System	Multi-point sequential electronic fuel injection
Ignition System	Fully-transistorized
Exhaust	Through Prop Hub Exhaust
Shaft Length	508 mm (20 in), 635 mm (25 in)
Fuel Type	Unleaded gasoline (87 octane or higher)
