DF140 “K2” (’02) MODEL 11-85
PROPELLER INSTALLATION
Install propeller stopper 1 onto propeller shaft, then slide on
the propeller 2.
Fit spacer 3, washer 4 and nut 5, then tighten nut to speci-
fied torque.
Push cotter pin 6 through nut and shaft, then bend to secure.
N 99000-25161: Water Resistant Grease
" Propeller nut: 55 N
.
m (5.5 kg-m, 40.0 lb-ft)
GEAR OIL
Fill the gearcase with specified gear oil for initial testing and
recheck the level after 10 minutes.
Top up if necessary.
L 99000-22540: Suzuki Outboard Motor Gear Oil

Suzuki DF 90 Specifications

General

Steering	Remote
Starting System	Electric
Number of Cylinders	4
Trim Method	Power Trim and Tilt
Full Throttle Operating Range	5, 500 - 6, 300 rpm
Fuel System	Multi-point sequential electronic fuel injection
Ignition System	Fully-transistorized
Exhaust	Through Prop Hub Exhaust
Shaft Length	508 mm (20 in), 635 mm (25 in)
Fuel Type	Unleaded gasoline (87 octane or higher)
