16-30 DF90/115/140 “K6” (’06) MODEL
2. Remove the upper thrust reverse mount 3.
3. Remove the two nuts 4 and upper mount plate 5.
4. Remove the four bolts 6 and upper mount covers 7.
Remove the upper mount assembly.
Reassemble the upper mount
When reassembling the upper mount parts, follow the removal
instruction in reverse. Also, paying close attention the parts ori-
entation shown below.
Install the upper mount plate with the UP mark pointing upside.

Suzuki DF 90 Specifications

General

Steering	Remote
Starting System	Electric
Number of Cylinders	4
Trim Method	Power Trim and Tilt
Full Throttle Operating Range	5, 500 - 6, 300 rpm
Fuel System	Multi-point sequential electronic fuel injection
Ignition System	Fully-transistorized
Exhaust	Through Prop Hub Exhaust
Shaft Length	508 mm (20 in), 635 mm (25 in)
Fuel Type	Unleaded gasoline (87 octane or higher)
