ELECTRICAL SYSTEM 15-12
Step 4
1) Measure the ignition coil resistance. (!15-14)
Is the ignition coil resistance OK?
Step 5
1) Measure the CKP sensor peak voltage and its resistance. (!15-15, -16)
Are the peak voltage and resistance OK?
Step 6
1) Measure the crankshaft rotation signal sensor peak voltage and its resistance. (!15-15, -16)
Are the peak voltage and resistance OK?
Step 7
1) Check the stator. (!15-9)
Is the stator OK?
Step 8
1) Measure the engine stop switch resistance. (!15-16)
Is the resistance OK?
YES Go to Step 5.
NO Faulty ignition coil
YES Go to Step 6.
NO
• Faulty CKP sensor
• Metal particles or foreign material being stuck on the CKP sensor and rotor tip
YES Go to Step 7.
NO
• Faulty crankshaft rotation signal sensor
• Metal particles or foreign material being stuck on the crankshaft rotation signal
sensor and rotor tip
YES Go to Step 8.
NO Faulty stator
YES
• Faulty ECM
• Open or short circuit in wire harness
NO Faulty engine stop switch
To Next Page
