Suzuki RM-Z450 Service Manual

SERVICING INFORMATION 20-27
HANDLEBAR SET-UP
66˚
55˚
30˚
90˚
1
7
5 m
m
(6
.8
9
in
)
Align the matching surface
of master cylinder with marking.
Align the matching surface of clutch
lever holder with marking.
Marking
Marking
Marking
105˚
Align the “ ” mark on the
throttle grip (L) with marking.
Apply adhesive to the
handlebars and inner of
throttle grip.
2
–
3 mm (0.08 –
0.12 in)
2
–
3 mm (0.08
–
0.12 in)
1
4
–
1
6
m
m
(0
.5
5
–
0
.6
3
in
)
1
9
0
m
m
(
7
.
4
8
in
)
Align the matching surface of
handlebar holder with marking.
Marking
Set the velcro of handlebar
pad to backward.
