FRONT FORK AND STEERING 18-6
• Clamp the axle holder

2 with a vise. Protect the axle holder
with a rag when using a vise.
• Loosen the center bolt

3 completely with a 21 mm socket
wrench.
• Compress the outer tube by hands and install the conrod
holder (special tool) between the axle holder bottom

2 and
lock-nut

4.
" 09910-20115: Conrod holder
• Hold the lock-nut with a wrench and remove the center bolt.
• Remove the push rod

5.
# WARNING
Clamping the axle holder too tight can damage it
which will affect riding stability.
Do not clamp the axle holder too tight.
