5. POINTS, EVENT MARKS
5-3
3. Edit the point referring to section 5.7.4.
4. Tap X on the title bar to close the menu.
Method 4: Input from external equipment
External equipment (fish finder, etc.) can output points to this equipment. TLL data
(NMEA 0183 format) from the external equipment is output to this equipment via an
NMEA data converter (IF-NMEA2K2, option). The latitude and longitude position of
the point is marked with the event icon.
5.2.2 How to enter an event mark
Method 1: Function gesture
This function is available by touch control when you tap [Event] in [Settings] - [General]
- [Function Gesture] (see section 1.15).
1. Tap the screen with two fingers to show the [Creating Events] pop-up menu. ([Re-
cord Event1 Automatically] on the [Points] menu must be set tor OFF to show this
pop-up.)
2. Tap required event mark.
The following occurs.
• The selected mark is put at the own ship position, on the plotter and radar displays,
at the moment the mark was selected.
• The event mark is saved to the points list.
Method 2: Slide-out menu
Open the slide-out menu, then tap [Event]. Tap required event mark in the [Creating
Events] pop-up menu. Note that is method is not available with the fish finder display.
To Next Page
