1. SYSTEM INTRODUCTION
1-9
1.2.4 Remote Control Unit group settings
If multiple Multi-Function Display are installed in the network, you can the select the
display to show on a unit, using the MCU-004 or MCU-005. Additionally, you can se-
lect the order in which to cycle through the displays.
Note: Confirm that there are no duplicate unit nicknames in the network. If a duplicate
name is found, change the name on the Sensor List ([Initial Setup][Sensor List]).
1. From the Home page, select [Settings][Initial Setup].
2. Tap the item [Remote Controller Configuration] twice.
Example remote configuration - MCU-004
*: For configurations with an MCU-005 connected, the nickname for the MCU-005
appears.
No. Description
1 The nickname automatically assigned to the MCU-004/MCU-005.
2 The nickname assigned to the Multi-Function Display unit currently being operated.
3 Setting for the unit connected to SMD12_FB_LEFT*, controlled by MCU1.
4 Set the cycling order of units controlled by MCU1. To skip a unit, select it to [Off].
5 Setting for the unit connected to SMD12_MB_LEFT*, controlled by MCU2.
6 Set the cycling order of units controlled by MCU2. To skip a unit, select it to [Off].
SMD12
SMD12
SMD12
MCU1-SMD12_FB_LEFT
MCU2-SMD16_MB_LEFT
SMD12
SMD12
SMD16
SMD16
SMD16
SMD16
