Sym Fiddle 50 User Manual

1. GENERAL INFORMATION
1-5
Specifications
Make SANYANG MODEL FA05 Series
Overall Length 1680 mm Front TELESCOPIC
Overall Width 750 mm
Suspension
System
Rear UNlT SWING
Overall Height 1070 mm Front 3.00 - 10 42J(T/L)
DIMENSION
Wheel Base 1170 mm
Tire
Specifications
Rear 3.00 - 10 42J(T/L)
Front 33 kg
Rear 50 kg
Front
DRUM (ψ 110mm)
Curb
Wei
g
ht
Total 83 kg
Brake
System
Rear
DRUM (ψ 95mm)
Passengers/
Weight
Two /110 kg Max. Speed 48 km/hr Below
Front 55 kg Climb Ability 20° Below
Rear 138 kg Primary Reduction BELT
WEIGHT
Total Weight
Total 193 kg
Secondary
Reduction
GEAR
Type Gasoline Clutch Centrifugal, dry type
Installation and
arrangement
Vertical, below center,
incline
PERFORMANCE
Transmission C.V.T.
Fuel Used Unleaded(92/95) Speedometer 0 ~ 90 km/hr
Cycle/Cooling
2-stroke/forced air
cooled
Horn 93 ~ 112 dB/A
Bore 39 mm Muffler Expansion & Pulse Type
Stroke 41.4 mm
Exhaust Pipe Position
and Direction
Right side, and Backward
Cylinder
Number/Arrang
ement
Single Cylinder Lubrication System Separated-lubrication
Displacement 49.4 cc
Compression Ratio 7.1 : 1
CO Below 1.2 g/km
Max. HP 2.1 kw / 6750 rpm
Exhaust
Concentration
HC+Nox Below 1.0 g/km
Max. Torque 3.5 Nm / 5500 rpm E.E.C. X
Ignition C.D.I. P.C.V. X
ENGINE
Starting System Electrical & kick
Catalytic reaction control
system
○
This chapter Contents

Sym Fiddle 50 Specifications

General

Brand	Sym
Model	Fiddle 50
Category	Scooter
Language	English
