13. STEERING/FRONT WHEEL/SUSPENSION
13-10
Front Cushion
Removal
Remove front fender.
Remove front cushion under bolt and nut.
Remove front cushion upper bolt, then remove
front cushion.
Installation
Install the removed components in reverse order
of removal procedures.
Torque value: 2.4~3.0kgf-m
Front cushion
This chapter Contents
Bolt
Bolt and nut
