2. SERVICE MAINTENANCE INFORMATION
2-1
General Information·································2-1
Periodical Maintenance Schedule ··········2-2
Air Cleaner················································2-3
Fuel Lines ·················································2-3
Fuel Filter··················································2-4
Engine Oil Line·········································2-4
Oil Pump Control Cable···························2-5
Tire ····························································2-6
Battery·······················································2-6
Rear Brake Free Play:····(Drum Brake Type)
···································································2-7
Steering System·······································2-8
Suspension ············································2-8
Transmission Oil····································2-9
Spark Plug·············································· 2-9
Control Cable Lubrication···················2-10
Driver Belt············································· 2-10
Ignition Timing····································· 2-10
Throttle Valve Operation····················· 2-10
Carburetor Idle Speed Adjustment····· 2-11
Carbon Removing For Exhaust Pipe &
Muffle····················································2-11
Cylinder Compression Pressure Test 2-11
Headlight Adjustment·························· 2-12
General Information
Specification
Tire dimension
Front: 3.00-10 42J
Rear: 3.00-10 42J
Tire pressure at cold Only rider
Front: 1.5kg/cm
2
Rear: 2.25 kg/cm
2
Front brake lever free play 10~20 mm
Rear brake lever free play 10~20 mm
Transmission oil Recommendation
Type: HYPOID GEAR OIL
Oil: SAE #140
Quantity: 0.1 L
Spark plug Recommendation
Type: NGK BR8HSA
Plug gap: 0.6-0.7mm
Driving belt width
Standard 18.0mm
Allowable limit: replace it if below 16.5mm
Ignition timing F mark
17°, BTDC/1500 rpm
Acceleration operation 2~6 mm
Idle speed
2000±100 rpm
Cylinder compression pressure
7±1 kgf/cm²
2
