3. LUBRICATION SYSTEM
3-1
Lubrication System Diagram············3-1
Precautions In Operation··················3-2
Lubricant ············································3-2
Trouble Shooting·······························3-2
Oil Pump Removal ····························3-3
Oil Pump Installation ························3-3
Oil Pump/Oil Tube Air Bleeding·······3-4
Oil Tank··············································3-5
Lubrication System Diagram
Oil pump
Oil output tube
Oil tube
Oil lever switch
Oil tank
