4. ENGINE REMOVAL
4-5
Remove engine mounting nut and bolt.
Engine installation
Install in the reverse order of removal procedures.
Tighten the engine mounting and rear shock
absorber upper/lower bolts.
Torque value:
Engine hanger bolt:
Rear shock absorber upper
mounting bolts:
Rear shock absorber lower
mounting bolts:
Exhaust pipe connection nut:
Muffle mounting bolt:
5.0kgf-m
4.0kgf-m
2.7kgf-m
1.2kgf-m
3.3kgf-m
Perform the following inspection and adjustment
after installation.
y Check if control cable is correct.
y Check if throttle valve cable is correct.
y Check if oil pump control cable is correct.
y Oil input and output of the oil pump.
y Adjust rear brake.
Engine mounting bolt
