6. List of accessories available upon request
The accessories mentioned below are available upon request.
Head accessories
Height adjustment device
Column stand
Mounting bracket(s)
Ez-Fix
Extra pair of glasses
Ref. 54807
• The CHR height adjustment system is used to adjust the
marking head height within a range of +/- 22.5 mm
(0.886 in).
• Positioned between the marking head and the support to
which the head is attached.
Ref. 58907
(Class 4)
• Marking machine support with height adjustment range of
300 mm (11.811 in).
• The marking head is attached to a column stand with a Z
axis. The Z axis is adjusted manually using the crank han-
dle and the ruler along the frame for positioning.
Ref. 58905
(Class 1 - with door)
• Marking machine support with height adjustment range of
50 mm (1.969 in).
• Compact Class 1 box with door for marking part up to
180 mm (7.087 in) high
Ref. 54808 This accessory is used to fasten the marking head on the height
adjustment device and on the column frame.
Ref. 66254 Used to rapidly fix small objects or items with various shapes.
Ref. 54577 Class 4: it is mandatory that the operator wear eye protection with
the suitable filter lenses.
