2. Generic Inputs/Outputs
 Connection of the I/O Phoenix connector
This connector allows the connection of generic Inputs/Outputs.
The connector consists of two parts, containing 8 inputs each.
Description
Number Function Type Comments
1-2 Input I0
Dry contact
Contact closing: Input activated
Contact opening: Input non-activated
3-4 Input I1
Dry contact
Contact closing: Input activated
Contact opening: Input non-activated
5-6 Input I2
Dry contact
Contact closing: Input activated
Contact opening: Input non-activated
7-8 Input I3
Dry contact
Contact closing: Input activated
Contact opening: Input non-activated
9-10 Input I4
Dry contact
Contact closing: Input activated
Contact opening: Input non-activated
10-12 Input I5
Dry contact
Contact closing: Input activated
Contact opening: Input non-activated
13-14 Output S0
Dry contact
Closed contact: Output active
Open contact: Inactive Output
15-16 Output S1
Dry contact
Closed contact: Output active
Open contact: Inactive Output
2
1
Connector rear view
16
15
