AInstallation

Ref. DCD01/3078 - TD412_en_C

25/62

4. Connections

Marking head + Laser module - View of connectors

1 : 17 point connector - Head/CCU connecting cable

2 : 19 point connector - Head/CCU connecting cable

3 : RF cord for module/CCU connection

4 : Optical fiber

The different elements of the equipment must be connected with the power off. The

power supply should be connected last.

Never disconnect the fiber from the module side.
