For TSCS models
Fig. 15
REFRIGERANT PIPING CONNECTION
For SC TSCS models
See ‘Quick Installation Guide’.
Fig. 16
G
T
he last 20 cm of the
refrigerant pipe, close to
the connector must be
kept straight. Bending can
cause leakage and is not
covered by the warranty.
G
CAUTION
For your safety, always wear safety eye wear and work gloves when connecting the pipes.
G
ATTENTION
All refrigerant work and refrigerant piping should comply with the local legislation, standards
and codes and should only be done by qualified and skilled people.
