TM 11-6625-2735-14-1
TABLE 1-3
PHYSICAL
Characteristics
Construction
Chassis
Panel
Cabinet
Circuit Boards
Overall Dimension
Height
With Feet and Pouch
Without Pouch
Width
With Handle
Without Handle
Depth
Including PaneI Cover
Handle Extended
Weight
With Panel Cover, Acces-
sories, and Accessory
Pouch
Without Panel Cover, Ac-
cessories, and Accessory
Pouch.
Domestic Shipping Weight
Export Shipping Weight
Information
Aluminum alloy.
Aluminum alloy with anodized finish.
Blue vinyl-coated aluminum alloy.
Glass laminate etched-wiring.
7.5 inches (19.1 cm).
6.2 inches (15.7 cm).
12.9 inches (32.8 cm).
11.5 inches (29.2 cm).
18.1 inches (46 cm).
20.3 inches (51.5 cm).
25.3 pounds (11.5 kg).
22.8 pounds (10.3 kg).
32.7 pounds (14.8 kg).
Approximately 48.0 pounds (21.8 kg).
Standard Accessories
Standard accessories supplied with the 475 are listed in the Mechanical Parts List, in this Service manual. For
optional accessories available for use with the 475, see the Tektronix, Inc., catalog.
1-12
