AFG3000 Series Arbitrary/Function Generators Service Manual 1-1
Specifications
These specifications apply to all AFG3000 Series Arbitrary/Function Generators.
All specifications are guaranteed unless labeled “typical”. Typical specifications
are provided for your convenience but are not guaranteed.
Specifications that are check marked with the ✔ symbol are checked directly (or
indirectly) in the Performance Verification section.
All specifications apply to the arbitrary/function generator unless noted otherwise.
These specifications are valid under the following conditions:
Performance Conditions
The performance limits in this specification are valid with these conditions:
The instrument must have been calibrated/adjusted at an ambient temperature
between +20
°C and +30 °C.
The instrument must be operating at an ambient temperature between 0 °C and
+50
°C.
The instrument must have had a warm-up period of at least 20 minutes.
The instrument must be in an environment with temperature, altitude, and
humidity within the operating limits described in these specifications.
Electrical
Table 1-1: Operation mode
Characteristics Description
Run mode Continuous, Modulation, Sweep, and Burst
Burst count 1 to 1,000,000 cycles or Infinite
Internal trigger rate 1.000 μs to 500.0 s
