Specifications
1-2 AFG3000 Series Arbitrary/Function Generators Service Manual
Table 1-2: Waveforms
Characteristics Description
Standard Sine, Square, Pulse, Ramp, More (Sin(x)/x, Noise, DC, Gaussian, Lorentz, Exponential Rise,
Exponential Decay, and Haversine)
Arbitrary waveform
Waveform length 2 to 131,072
Sampling rate
AFG3021B, AFG3022B,
AFG3011
250 MS/s
AFG3101, AFG3102 Waveform length ≤ 16384: 1 GS/s
16384 < waveform length: 250 MS/s
AFG3251, AFG3252 Waveform length ≤ 16384: 2 GS/s
16384 < waveform length: 250 MS/s
Resolution 14 bits
Number of non-volatile waveform
memories
4
Table 1-3: Frequency and period
Characteristics Description PV reference
page
Frequency range
Sine
1
AFG3011 1 μHz to 10 MHz
AFG3021B, AFG3022B 1 μHz to 25 MHz
AFG3101, AFG3102 1 μHz to 100 MHz
AFG3251, AFG3252 1 μHz to 240 MHz
Square
AFG3011 1 μHz to 5 MHz
AFG3021B, AFG3022B 1 μHz to 12.5 MHz
AFG3101, AFG3102 1 μHz to 50 MHz
AFG3251, AFG3252 1 μHz to 120 MHz
Pulse
AFG3011 1 mHz to 5 MHz
AFG3021B, AFG3022B 1 mHz to 12.5 MHz
AFG3101, AFG3102 1 mHz to 50 MHz
AFG3251, AFG3252 1 mHz to 120 MHz
