Specifications
1-12 AFG3000 Series Arbitrary/Function Generators Service Manual
General
Table 1-12: Rear panel
Characteristics Description
External modulation input
Input range ±1.0 V full scale (except FSK)
3.3 V logic level (FSK)
Impedance 10 kΩ
Frequency range AM, FM, PM, FSK, PWM: DC to 25 kHz (sampling rate: 122 kS/s)
External reference output AFG3011, AFG3101, AFG3102, AFG3251, and AFG3252
Impedance 50 Ω, AC coupled
Amplitude 1.2 V
p-p
into 50 Ω
External reference input
Impedance 1 kΩ, AC coupled
Required input voltage swing 100 mV
p-p
to 5 V
p-p
Lock range 10 MHz ± 35 kHz
CH1 Additional input AFG3101, AFG3102, AFG3251, and AFG3252
Impedance 50 Ω
Input range –1 V to +1 V (DC + peak AC)
Bandwidth DC to 10 MHz (–3 dB) at 1 V
p-p
Table 1-13: System characteristics
Characteristics Description
Warm-up time, typical 20 minutes minimum
Power on self calibration, typical < 16 s
Configuration times, typical USB LAN GPIB
Function change 95 ms 103 ms 84 ms
Frequency change 2 ms 19 ms 2 ms
Amplitude change 60 ms 67 ms 52 ms
Select user Arb 88 ms 120 ms 100 ms
Data download, typical 4000 points waveform data
GPIB: 42 ms
USB: 20 ms
LAN: 84 ms
Acoustic noise, typical < 50 dBA
Weight (approximate) 4.5 kg
Dimensions See Figure 1-1 and Figure 1-2 on page 1-17
