Appendix A: Specifications
A-30
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
Table A- 4: Serial Trigger specifications (optional on TDS7000 Series & TDS6000 Series) (Cont.)
Characteristic Description
Clock recovery jitter, typical <0.25% bit period + 9 ps rms for PRBS data patterns.
<0.25% bit period + 8 ps rms for repeating 0011 data patterns.
Clock recovery tracking/acquisition range, typical ±5% of requested baud
Minimum si gnal amplitude needed for clock
recovery, typi cal
1 division p-p up to 1.25 GBd
1.5 divisions p-p above 1.25 GBd
Table A- 5: Display specifications
Characteristic Description
Display type 211.2 mm (8.4 in) (W)× 158.4 mm (6.3 in) (H), 264 mm (10.4 in) diagonal, liquid
crystal active-matrix color display
Display resolution 640 horizontal × 480 vertical pixels
Pixel pitch 0.33 mm horizontal, 0.22 mm vertical
Response time, typical 50 ms, black to white
Display refresh rate 59.94 frames per second
Viewing angle, typical 80 degrees
Displayed intensity levels Supports Windows SVGA high-color mode (16-bit)
