Tektronix TDS7054 Service Manual

Mechanical Parts List
10- 2
TDS7104 & TDS7054 Service Manual
Using the Replaceable Parts List
This section contains a list of the mechanical and/or electrical components that
are replaceable for the oscilloscope. Use this list to identify and order replace-
ment parts. The following table describes each column in the parts list.
Parts list column descriptions
Column Column name Description
1 Figure & Index Number Items in this section are referenced by component number.
2 Tektronix Part Number Use this part number when ordering replacement parts from Tektronix.
3 and 4 Serial Number Column t hree indicates the serial number at which the part was first effective. Column four
indicates t he serial number at which the part was discontinued. No entries indicates the part is
good f or all serial numbers.
5 Qty This indicates the quantity of parts used.
6 Name & Description An item name is separated from the description by a colon (:). Because of space limitations, an
item nam e may sometimes appear as incomplete. Use the U.S. Federal Cat alog handbook
H6-1 for further item name identification.
7 Mfr. Code This indicates the code of the actual manufacturer of the part. (Code to name and address cross
reference is located after this page.)
8 Mfr. Part Number This indicates the actual manufacturer’s or vendor’s part num ber.
Abbreviations conform to American National S tandard ANS I Y1.1--1972.
The following table cross indexes codes, names, and addresses of manufacturers
or vendors of components listed in the parts list.
Manufacturers cross index
Mfr.
code
Manufacturer Address City, state, zip code
00779 AMP INC. CUSTOMER SERVICE DEPT
PO BOX 3608
HARRISBURG, PA 17105--3608
00779 TYCO ELECTRONICS CORPORATION CUSTOMER SERVICE DEPT~PO BOX 3608 HARRISBURG, PA 17105--3608
01963 CHERRY ELECTRICAL PRODUCTS CO 3600 SUNSET AVENU E WAUKEGAN, IL 60087--3214
049S6 FUJIT SU COMPUTER PRODUCTS OF
AMERICA INC
2904 ORCHARD PARKWAY SAN JOSE, CA 95134--2009
05791 LYN--TRON INC SOUTH 6001 THOMAS MALLEN RD SPOKANE, WA 99204
060D9 UNITREK CORPORATION 3000 COLUMBIA HOUSE BLVD, SUITE 1
20
VANC OUVER, WA 98661
06915 RICHCO 5825 N TRIPP AVE
P.O. BOX 804238
CHICAGO, IL 60646
07416 NELSON NAME PLATE COMPANY 3191 CASITAS AVENUE LOS ANGELES, CA 90039--2410
Abbreviations
Mfr. Code to Manufacturer
Cross Index
