Specifications
TDS7104 & TDS7054 Service Manual
1-15
Table 1- 4: Trigger specifications (Cont.)
Characteristic Description
Advanced t rigger timer ranges Limits
Glitch type 1nsto1s
Runt type, time qualified 1nsto1s
Width type 1nsto1s
Timeout type 1nsto1s
Transition type 1nsto1s
Pattern type 1nsto1s
Setup/Hold t y pe Setup and Hold timers Limits
Setup time (time from data
transition t o clock edge)
--100 ns to +100 ns
Hold time (time from clock
edge t o data transition)
--1 ns to +100 ns
Setup time + Hold time
(algebraic sum of the two
settings)
+2 ns
n Advanced trigger timer accuracy For Gli tch, Tim eout, or Width types
Time range Accuracy
1 ns to 500 ns ±(20% of setting + 0.5 ns)
520 ns to 1 s ±(0.01% of setting +
100 ns)
Tri gger holdoff range 250 ns to 12 s,
minimum resolution is 8 ns for settings ≤1.2 ms
Table 1- 5: Display specifications
Characteristic Description
Display type 211.2 mm (W)× 158.4 mm (H), 264 mm (10.4 in)
diagonal, l iquid cryst al act ive-matrix color display
Display resoluti on 640 horizontal × 480 vertical pixels
Pixel pitch 0.33 mm horizontal, 0.22 mm vertical
Contrast ratio, typical 150:1
Response t ime, typic al 50 ms, black to white
Display refresh rate 59.94 frames per second
Displayed int ensity levels Supports Windows SVGA high-color mode (16-bit)
