Tektronix TG8000 Programmer's Manual

GPS7 GPS Synchronization and Timecode module remote commands
Table 5: GPS7 ve
rtical timing offset ranges
Standard / frame rate Range
NTSC
±525
PAL ±1250
1080 ± 562HD
720 ±375
:SENSe<n>:CORRection:MDELa y:VERTical
Returns the current vertical timing offset of the selected outputs. The <n> in
the command represents the output connector. "1" represents the BLACK1
connector, "2" represents the BLACK2 connector, and "3" represents the
BLACK3 connector.
:SENSe<n>:CORRection:MDELa y:VERTical:STEP <numeric_value>
Sets the step increment used by the UP or DOWN commands. You c an use
MIN, MAX, or DEF i nstead of a numeric value. See page 2-2 for additional
detail on MIN, MAX , and DEF. The <n> in the command represents the
type of
output connector. "1" represents the SIGNAL connectors and "2"
represents the BLACK connectors.
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 97
