SDI7 Dual Channel SD/HD/3G SDI Video Generator module remote commands
Returns the P
B
/
B/Y component setting for the zone plate test pattern.
:OUTPut<1|2>:ZONE:VIDEO:PR :STATe <Boolean>
Enables or disables the P
R
/R/Z component of the z one plate test pattern,
depending on the selected sampling structure.
:OUTPut<1|2>:ZONE:VIDEO:PR :STATe?
Returns the P
R
/R/Z component setting for the zone plate test pattern.
SENSE commands
Use these commands to set the timing o f the SDI7 module relative to the internal
reference signal (frame reset signal).
Command tree
:SENSe<1|2>
:CORRection
:MDELay
:HORizontal
<NR2>
:Horizontal
:VERTical
<NR1>
:Relative
<ANALog
|
SERia
l>
Command description
:SENSe<1|2>:CORRection:MDE Lay:HORizontal <NR2>
Sets the horizontal timing offset o
f the selected outputs. The timing resolution
is clock-cycles. The units are microseconds. (See Table 7.)
Table 7: SDI7 horizontal offset ranges
Standard / F rame rate
Range μs
(± 1 video line) Resolution
1080 60p 14.814
.0067μs (148.5 MHz clock)
1080 59.94p 14.829
.0067μs (148.36 MHz clock)
1080 50p 17.778
.0067μs (148.5 MHz clock)
1080 60i 29.629
.0135μs (74.25 MHz clock)
1080 59.94i 29.659
.0135μs (74.18 MHz clock)
1080 50i 35.556
.0135μs (75.25 MHz clock)
1080 30p / sF
29.629
.0135μs (75.25 MHz clock)
1080 29.97p / sF
29.659
.0135μs (74.18 MHz clock)
1080 25p / sF
35.542
.0135μs (75.25 MHz clock)
1080 24p / sF
37.037
.0135μs (75.25 MHz clock)
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 171
