Field Description
• ' (default value): RIP is not enabled.
• @ 6: Enables sending and receiving of version 1 RIP
packets.
• @ 6: Enables sending and receiving of version 2 RIP
packets.
• @ 656:Enables sending and receiving RIP packets of
both version 1 and 2.
• @ 6 ( : RIP V1 messages are sent, received
and processed as per RFC 2091 (triggered RIP).
• @ 6 ( : RIP V2 messages are sent, received
and processed as per RFC 2091 (triggered RIP).
Route Announce Select this option if you want to set the time at which any activ-
ated routing protocols (e.g. RIP) are to propagate the IP routes
defined for this interface.
Note: This setting does not affect the interface-specific RIP con-
figuration mentioned above.
Possible values:
• 0) . (not for LAN interfaces, interfaces in Bridge
mode and interfaces for leased lines): Routes are propagated
if the interface status is up or ready.
• 0) ,& (default value): Routes are only propagated if the
interface status is up.
• -,1&#: Routes are always propagated independently of op-
erational status.
15.1.2 RIP Filter
In this menu, you can specify exactly which routes are to be exported or imported.
You can use the following strategies for this:
• You explicitly deactivate the import or export of certain routes. The import or export of all
other routes that are not listed is still allowed.
• You explicitly activate the import or export of certain routes. In this case, you must also
explicitly deactivate the import or export of all other routes. This is achieved using a filter
for IP Address / Netmask = no entry (this corresponds to IP address 0.0.0.0 with net-
mask 0.0.0.0). To make sure this filter is used last, it must be placed at the lowest posi-
Teldat GmbH
15 Routing Protocols
bintec Rxxx2/RTxxx2 241
