Terex R190T Service Manual

2.17 Transporting the Machine
• Use only suitable transport and lifting equipment with sufficient carrying
capacity.
• Load the machine on firm and level ground.
• Before driving onto the ramps, clean them and the machine tracks of any
materials that may cause slippage (snow, ice, water, mud, sludge, oil, etc.).
• Properly align the machine with the loading ramp.
• Have a guide give the machine operator any necessary signs to maximize
safety during loading.
• Move carefully onto the ramps and transport vehicle.
• Before you leave the machine, relieve all residual pressure by making sure
all operating levers and switches are in their neutral positions. Remove the
ignition key.
• Secure the door, windows and hood on the machine.
• Secure the machine and any other items against slipping with chains, ropes
of the proper capacity.
• Before departure, investigate the route to be taken, especially in regard to
limits for width, height and weight.
• Pay close attention when driving under electrical lines, bridges, or through
tunnels.
• Use the same caution when unloading as for loading. Remove all
cables/chains. Start the engine as described in the operating instructions.
Carefully drive down the ramp from the transport vehicle using a guide if
necessary to direct movement.
• When lifting attachments or components, use caution. Attach straps or
chains securely and in such a way that they evenly distribute the weight of
the item to be lifted, ensuring a balanced load. Stay clear of expected travel
path.
2 SAFETY
23
R160T / R190T US O&M
0404-490 2014-06

Terex R190T Specifications

General

Horsepower	74 hp
Rated Operating Capacity	1, 900 lbs
Bucket Width	72 in
Travel Speed	7.5 mph
Width	72 in

Summary

Introduction

Product Identification and Safety Alerts

Identifies the machine's PIN and explains safety alert symbols.

Operational Guidelines and Support

Covers intended use, bulletin compliance, and contacting manufacturer for support.

Warranty and Compliance Information

Details the machine's warranty and Tier 4f compliance information.

Safety

Safety Alert System and Hazard Classification

Explains safety alert symbols and hazard levels like DANGER, WARNING, CAUTION.

Graphical Safety Symbols

Illustrates and describes various hazard and avoidance symbols used in the manual.

ANSI Safety Sign Locations

Shows placement of safety signs on the machine with a key.

Personal Protection and Hazard Zones

Details required PPE and defines the operational hazard zone.

Technical Data

General Machine Structure and Views

Identifies key components of the machine with diagrams and visual overviews.

Engine, Electrical, and Undercarriage Specifications

Details engine type, electrical system, and undercarriage characteristics.

Transmission, Hydraulics, and Capacities

Provides specifications for transmission, hydraulics, ground pressure, and fluid capacities.

Fluid Specifications and Dimensions

Lists fluid specifications and physical dimensions/weights of the machine.

Machine Description / Controls

Display Elements and Indicators

Explains the function of various indicators, switches, and gauges on the control panel.

Machine Symbols

Illustrates and defines symbols used on the machine's controls and displays.

Operator Controls Overview

Details the operation of the main drive and lift arm joysticks.

Key Control Functions

Describes the throttle lever, two-speed system, and optional bucket positioning feature.

Operation

Pre-Operation Checks and Starting Procedures

Outlines general operation, pre-operation safety checks, and engine starting procedures.

Basic Operation: Filling, Grading, and Leveling

Advises on surface preservation, filling the bucket, and performing grading/leveling tasks.

Loading and Attachment Handling

Details loading materials and securely fastening/unfastening attachments.

Incline Operation, Shut-Down, and Lift Arm Brace

Covers safe operation on inclines, machine shut-down, and lift arm brace usage.

Transportation

Safe Machine Transport

Details precautions for safely transporting the machine on a trailer or truck.

Towing and Retrieving Procedures

Explains how to safely tow or retrieve the machine when it's inoperable.

Loading and Unloading Procedures

Provides step-by-step instructions for safely loading and unloading the machine.

Maintenance

General Care and Maintenance Schedule

Emphasizes the importance of maintenance and outlines the overall service schedule.

Lubrication Points and Fluid Checks

Identifies daily lubrication points and outlines engine oil level checking procedures.

Engine Oil and Filter Service

Provides instructions for changing the engine oil and filter.

Hydraulic Oil and Filter Service

Describes the steps for changing the hydraulic oil and filter.

California Proposition 65

California Proposition 65 Warning

Provides legally required warnings about chemicals emitted by the equipment.
