3 TECHNICAL DATA
33
3.6 Transmission R160T [R190T]
3.7 Auxiliary Hydraulics R160T [R190T]
3.8 Ground pressure R160T [R190T]
3.9 Operating Specs. R160T [R190T]
Note: The Maximum Gross Vehicle Weight of the R160T/R190T is not to exceed
8500 lb. (3856 kg). This excludes an operator, but does include accessories,
attachments and material being carried.
3.10 Capacities (approx) R160T [R190T]
Make
Rexroth Rexroth
Type
A22VG A22VG
Design
Variable disp. / axial piston Variable disp. / axial piston
Discplacement
2.35 in. ³ (38.5 cc) / rev. 2.35 in. ³ (38.5 cc) /rev.
Relief Pressure
5500 psi (37,920 kPa) 5500 psi (37,920 kPa)
Make
Barnes-Haladex Barnes-Haladex
Type
180-2061 180-2061
Design
Gear Gear
Displacement
1.34 in. ³ (22 cc)/revolution 1.34 in. ³ (22 cc)/revolution
Relief pressure
3000 psi (20,684 kPa) 3000 psi (20,684 kPa)
Flow (2800 RPM)
17.4 gpm (65.9 lpm) 17.4 gpm (65.9 lpm)
At operatin
g
wei
g
ht
3.5 psi (24.1 kPa) 3.6 psi (24.7 kPa)
Tipping load
4574 lb (2074 kg) 5428 lb (2462 kg)
Operating capacity 50%
2285 lb (1036 kg) 2714 lb (1231 kg)
Operating capacity 35%
1600 lb (725 kg) 1900 lb (861 kg)
Fuel tank
13.7gal(51.9l) 13.7gal(51.9l)
Hydraulic tank
8gal(30.3l) 8gal(30.3l)
Engine coolant
2gal(7.5l) 2gal(7.5l)
Engine oil including filter
2.8gal(10.6l) 2.8gal(10.6l)
R160T / R190T US O&M
0404-490 2014-06
