5.3 Starting Procedure
Before starting the engine, perform the pre-operation safety checklist. Once com-
plete, you may proceed by following this procedure:
1. Enter machine with lift arms all the way down. Maintain three points of
contact with the machine (fig. 5.3-1).
2. Sit down into the operator’s seat, fasten seat belt, then lower lap bar into
position.
3. Starting with the throttle in the SLOW (turtle icon) position, push the throttle
1/3 the way open (toward the rabbit icon).
4. Turn the ignition key to the left for 6 seconds to “pre-heat” the engine.
While pre-heating, the glow plug operation light will illuminate.
5. Turn the ignition key to the right to start the engine.
6. Let the engine run at low idle for 2 to 3 minutes to warm it.
7. Set the throttle to desired rpm for operation.
Note: The parking brake is automatically engaged when the engine is turned off,
the operator is not in the seat or the lap bar is raised.
48
5.3-1 5.3-2
Entering or exiting the vehicle under raised lift arms could result in injury or
death. Never allow anyone beneath raised, unsecured lift arms (fig. 5.3-2).
R160T / R190T US O&M
0404-490 2014-06
