7.16 Air Cleaner Removal / Inspection
The air cleaner is one of the most important maintenance items on the machine.
Regular inspection and replacement is necessary to ensure proper performance
and to prolong engine life. Inspect the air cleaner elements daily. If damaged
or heavily soiled, clean or replace the elements.
1. Shut the machine down according to the procedure in section 5.13, then
open the hood to access the air cleaner. Release the latches on either side
of the air cleaner housing, then remove the cover.
2. Remove the primary element (1). The primary element can be cleaned and
reused up to five times, but should be changed at least once a year.
3. Remove the secondary element (2). The secondary element is not
serviceable or washable. The secondary element should be replaced every
three cleanings of the primary element.
74
2
1
R160T / R190T US O&M
0404-490 2014-06
7.16-1 7.16-2
