Greensmaster Flex 18/21Page 3 – 2Engine
Specifications
Item Description
Make / Designation Kawasaki, 4–stroke, OHV, single cylinder,
air–cooled, gasoline engine, FE120D
Bore x Stroke 2.36” x 1.73” (60 mm x 44 mm)
Total Displacement 7.6 in
3
(124 cc)
Compression Ratio 8.4:1
Carburetor Float feed, fixed main jet
Governor Mechanical flyweight
Low Idle Speed (no load) 2400 + 100 RPM
High Idle Speed (no load) 3600 + 100 RPM
Direction of rotation Counter clockwise (facing PTO shaft)
Fuel Unleaded, automotive grade gasoline
Fuel Tank Capacity 2.6 U.S. qt (2.5 l)
Engine Oil See Operator’s Manual
Lubrication System Splash type
Oil Capacity 0.63 U.S. qt (0.6 l)
Air Cleaner Dual element
Ignition System Transistorized flywheel magneto with ignition advance
Spark Plug NGK BPR 5ES
Spark Plug Gap 0.028” to 0.032” (0.7 to 0.8 mm)
Dry Weight 32.4 lbs (14.7 kg)
Engine
