Greensmaster Flex 18/21 Traction and Reel Drive SystemPage 4 – 1
Chapter 4
Traction and Reel Drive System
Table of Contents
SPECIFICATIONS 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL INFORMATION 3. . . . . . . . . . . . . . . . . . . . .
Operator’s Manual 3. . . . . . . . . . . . . . . . . . . . . . . . . .
Gearbox Seals 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SERVICE AND REPAIRS 5. . . . . . . . . . . . . . . . . . . . . .
Reel Drive and Transmission Coupler
Drive Belt Replacement 5. . . . . . . . . . . . . . . . . . . .
Reel Drive Assembly 6. . . . . . . . . . . . . . . . . . . . . . . .
Reel Drive and Transmission Coupler
Bearing Housing 7. . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Drive Belt Replacement 10. . . . . . . . . . . . .
Traction Drive Idler Pulley and Bearings 11. . . . . . . .
Traction Drum Assembly 12. . . . . . . . . . . . . . . . . . . .
Gearbox 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gearbox Service 18. . . . . . . . . . . . . . . . . . . . . . . . . . .
Differential Service 22. . . . . . . . . . . . . . . . . . . . . . . . .
Traction and Reel
Drive System
