WARNING
Themachineisshippedwiththepowertakeoff(PTO)universalshaftattachedtotheframe.
DonotoperatethePTOwithoutrstremovingtheuniversalshaftorcouplingittoasuitable
implement.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
InstallingtheSteering
Wheel
Partsneededforthisprocedure:
1
Steeringwheel
1
Cover
Procedure
1.Removethesteeringwheelfromtheshipping
skid(Figure3).
g001190
Figure3
1.Steeringwheel
4.Foamcollar
2.Jamnut
5.Cover
3.Dustcover6.Washer
2.Removethejamnutandwasherfromthe
steeringshaft.
Note:Ensurethatthefoamcollaranddust
coverremainonthesteeringshaft(Figure3).
3.Slidethesteeringwheelandwasherontothe
steeringshaft(Figure3).
4.Securethesteeringwheeltotheshaftwith
thejamnut.Tightenthejamnutto27-35N∙m
(20-26ft-lb).
5.Mountthecovertothesteeringwheel(Figure3).
2
InstallingtheHoodHandle
Partsneededforthisprocedure:
1Handle
2
Screws
Procedure
1.Removeanddiscardthe2screwsandnuts
securingthehoodcablebracketandtothe
undersideofthehood(Figure4).
g198431
Figure4
1.Hoodcablebracket
2.Mountthehandleandthecablebrackettothe
hoodwith2screws(Figure5).
12
