AccessingtheFuseBlock
andStandardControl
Module
RemovingtheControl-PanelPlate
1.Removethe4thumbscrewsthatsecurethe
control-panelplatetothefueltank(Figure52).
g198540
Figure52
1.Fueltank
3.Control-panelplate
2.Thumbscrew
2.Liftthecontrol-panelplate(Figure52).
3.Disconnecttheelectricalconnectorsfromthe
switchesandwarninglightsasnecessaryto
accessthefuseblockorthestandardcontrol
module.
InstallingtheControl-PanelPlate
1.Connecttheelectricalconnectorstotheswitches
andwarninglightsthatyoudisconnectedinstep
3ofRemovingtheControl-PanelPlate(page
48).
2.Alignthe2tabsatthebottomofthesidepanel
withthe2slotsintheframefortheconsole
(Figure53).
g034111
Figure53
1.Tabs(sidepanel)2.Slots(frame—console)
3.Aligntheslotsinthetopofthecontrol-panel
platewiththeholesintheangeofthefueltank
(Figure52).
4.Assemblethecontrolpanelplatetotheange
ofthefueltankwiththe4thumbscrews(Figure
52)thatyouremovedinstep1ofRemovingthe
Control-PanelPlate(page48).
48
