5.Afterattainingthedesiredwheelalignment,
assembleballjointtothemountingbracketwith
thecastlenutandcotterpin.
6.Tightenthelocknutandboltatthetie-rodclamp.
TorquingtheBoltsforthe
Steering-CylinderMount
4-WheelDriveMachinesOnly
ServiceInterval:Every200hours
1.Movethemachinetoalevelsurface,shutoffthe
engineandremovethekeyfromthekeyswitch.
2.Torquethe4boltsforthesteering-cylinder
mount(Figure64)to65to81N∙m(48to60ft-lb).
g003496
Figure64
1.Bolt—4each(steering-cylinder-mount)
AdjustingtheTraction
Drive
Ifthemachinemoveswhenthetractionpedalisinthe
neutralposition,adjustthetractioncam.
PreparingtoAdjusttheTraction
Drive
Liftingequipmentandjackstandcapacity:1900
kg(2ton)orgreater
1.Movethemachinetoalevelsurface,shutoffthe
engine,andengagetheparkingbrake.
WARNING
Ifthemachineisnotsupported
adequately,itmayaccidentallyfall,
injuringanyoneunderthemachine.
Raiseall4wheelsoffthegroundorthe
machinemaymovewhileadjustingthe
tractiondriveforneutral.
2.Raisethemachineandsupportitwith4jack
standsofthespeciedcapacityundertheframe.
3.Removetheseatandseatplate;referto
RemovingtheSeatandSeatPlate(page39).
54
