General Specifications (continued)
Interlock Switches
PTO switch—shuts engine off when PTO is engaged with no operator in seat.
Traction switch—shuts engine off when traction pedal is engaged with no operator
in seat. Seat switch—shuts engine off if operator leaves seat without disengaging
PTO and/or traction pedal. Engine will not start if PTO or traction pedal is engaged.
Brake switch–shuts engine off when PTO or traction pedal is engaged with parking
brake set.
Instrument Panel and
Control
Hour meter, fuel gauge, ignition switch, oil pressure warning light, charge indicator,
engine coolant temperature warning light, temperature gauge, temperature override
switch, glow plug indicator light and throttle control are on instrument panel. Hand
operated PTO lever is located to right of the seat. Traction pedal for traction
operation at right of steering column.
PTO Drive
Shaft is driven by a tight-slack double “A” section, torque team V-belt directly from
output shaft of engine. Shaft is clutched by pivoting the shaft support with a spring
loaded, over center, hand operated lever. PTO speed 1810 RPM @ 3200 RPM
engine speed. Connection to implement is with high quality, needle bearing
universal joint with slip joint.
Implement Lift
Cutting unit or implement is lifted by hydraulic cylinder that has 2-1/2 in. (64 mm)
bore and 3-1/4 in. (82 mm) stroke.
Dimensions and Weights
(approx.)
Width (measured from
outside of front tires)
46 in. (117 cm)
Length 91 in. (231 cm)
Height 50 in. (127 cm)
Height w/ROPS 78.5 in. (199 cm)
Dry Weight – 2 Wheel
Drive w cutter deck
1650 lb. (743 kg)
Dry Weight – 4 Wheel
Drive
2065 lb. (929 kg)
Wheel Base 49 in. (124 cm)
Attachments/Accessories
A selection of Toro approved attachments and accessories
are available for use with the machine to enhance and
expand its capabilities. Contact your Authorized Service
Dealer or Distributor or go to www.Toro.com for a list of
all approved attachments and accessories.
