Toro Groundsmaster 4100 User Manual

g001055
Figure11
CheckingtheTorqueofthe
WheelLugNuts
ServiceInterval:Afterthersthour
Aftertherst10hours
Every200hours
WARNING
Failingtomaintainpropertorqueofthe
wheel-lugnutscouldresultinpersonalinjury.
Torquethewheel-lugnutstotheproper
torquevalue.
Torquethewheel-lugnutsto115to136N∙m(85to100
ft-lb)intheordershowninFigure12andFigure13.
g033358
Figure12
FrontWheels
g033359
Figure13
RearWheels
AdjustingtheMirrors
CabModelOnly
RearviewMirror
Whilesittingintheseat,adjusttherearviewmirrorto
attainthebestviewouttherearwindow(Figure14).
Pulltheleverrearwardtotiltthemirrortoreducethe
brightnessandglareoflight.
Side-ViewMirrors
Whilesittingintheseat,havesomeoneassistto
adjusttheside-viewmirrorstoattainthebestview
aroundthesideofthemachine(Figure14).
g008870
Figure14
1.Side-viewmirrors
3.Lever
2.Rearviewmirror
24
