AimingtheHeadlights
OptionalAccessory
1.Loosenthemountingnutsandpositioneach
headlightsothatitpointsstraightahead.
Note:Tightenthemountingnutjustenoughto
holdtheheadlightinposition.
2.Placeaatpieceofsheetmetaloverthefaceof
theheadlight.
3.Mountamagneticprotractorontotheplate.
4.Whileholdingtheassemblyinplace,carefullytilt
theheadlightdownward3°,thentightenthenut.
5.Repeattheprocedureontheotherheadlight.
AdjustingtheRollover
ProtectionSystem(ROPS)
WARNING
Toavoidinjuryordeathfromrollover:keep
therollbarintheraisedlockedpositionand
usetheseatbelt.
Ensurethattheseatissecuredwiththeseat
latch.
WARNING
Thereisnorolloverprotectionwhentheroll
barisinthedownposition.
•Donotoperatethemachineonuneven
groundoronahillsidewiththerollbarin
thedownposition.
•Lowertherollbaronlywhenabsolutely
necessary.
•Donotweartheseatbeltwhentherollbar
isinthedownposition.
•Driveslowlyandcarefully.
•Raisetherollbarassoonasclearance
permits.
•Checkcarefullyforoverheadclearances
(i.e.,branches,doorways,electricalwires)
beforedrivingunderanyobjectsanddo
notcontactthem.
LoweringtheRollBar
g221650
Figure15
RaisingtheRollBar
g221651
Figure16
25
