6
Controller Programming
NOTE: English display prompts and 12-hour (a.m./p.m.) time format are factory-default settings. To
select an optional display language, including Spanish, French, Italian, German and Portuguese,
and/or a 24-hour time format, refer to the Special Function setup procedures on page 13.
Set Current Time and Date
1. Turn the Function Dial clockwise to Current Time/Day . The hour digits will begin flashing.
2. Adjust the display by pressing the or buttons.
NOTE: Hold either button down for rapid advance.
3. Press the button to select the next field.
4. Repeat steps 2 and 3 to set the current minutes, year, month and day (current weekday will
be set based on calendar setting).
5. Return the Function Dial to RUN when finished.
Select the Program
NOTE: If the controller has been previously programmed, the user-defined program settings can be
quickly erased and reset to factory defaults. See “Using the Program Memory Erase Feature” on
page 13.
To simplify the programming process, the following procedures are provided to define the
operating parameters of one program at a time.
To begin, set the program switch to select program A, B, C, or D.
Set Station Run Time
A station is assigned to the selected program when it is given a run time duration. The station can
have only one run time assignment per program, but can have a separate run time assignment in
each program. By default, station run time is defined in minutes and hours. To enable station run
time to include seconds, see “Station Runtime Display Format” on page 13.
1. Turn the Function Dial to Station Times .
2. Press the
or button to select the station number. The corresponding station output
terminal will be shown on the display as a solid circle.
3. Press the or buttons to adjust the station run time from Off (-- -- --) to 1 minute – 8
hours (in 1-minute increments). If seconds format is enabled, station run time can be set from
01–60 seconds.
NOTE: Hold either button down for rapid advance.
4. Repeat steps 2 and 3 for all stations to be assigned to the selected program.
