NOTE: A program must have the MV/PS control option enabled to permit individual stations
assigned to the program to be excluded from MV/PS operation. In other words, assigning MV/PS
operation by station is not applicable unless MV/PS operation for its assigned program is enabled.
• Master Valve/Pump Start Operation by Program
1. Set the Program Switch to select program A, B, C, or D.
2. Turn the Function Dial to Special Functions .
3. Press the button to display MVA -- Y (Master Valve [program A] - Yes [on]).
4. To exclude the selected program from MV/PS operation, press the or button to select
MV[A] – N (Master Valve [program A] – No).
• Master Valve/Pump Start Operation by Station
1. Press the button to display MVS -- N (Master Valve Stations – No).
2. To access this option, the option must first be enabled by pressing the
or button to select MVS -- Y (Yes). By default, all station identifiers will be solid circles
(all enabled).
3. Press the button to select MV -- Y 01 (Master Valve--Yes, station 01).
The station identifier will begin flashing.
4. Press the button to exclude selected station, or press the button to skip the station.
When excluded, the station identifier will change from solid to hollow. The next station identi-
fier in sequence will begin flashing.
5. Repeat the procedure in step 4 as needed for each station.
• To Set Pump Delay
This feature enables a delay period from 1 to 60 seconds to occur after the MS/PS circuit is activated,
and prior to the start of the first station in the watering sequence. This delay feature is often used in
conjunction with the Station Delay (SD) feature.
1. Set the Program Switch to select program A, B, C, or D.
2. Turn the Function Dial to Special Functions .
3. Press the
button (as needed) to display PD -- -- (Pump Delay Off).
4 . Press the or button to select the delay time value from 01 to 60 seconds.
• To Set Pump Enable
This feature allows you to enable or disable MV/PS operation for the duration of a Station Delay
period.
1. Set the Program Switch to select program A, B, C, or D.
2. Turn the Function Dial to Special Functions .
3. Press the button as needed to display PE - - N (Pump Enable - No [Off]).
4. Press the or button to select PE - - Y (Pump Enable - Yes [On]).
11
