Toro TMC-424E User Manual

NOTE:
•
= Do not operate in this region
• TMC-424E maximum PPS = 125
• To convert GPM to LPM, multiply x 3.79
• If installed flow sensor measures in units other than PPS, contact your Toro distributor for
assistance.
Appendix A – TFS Series Flow Sensor Performance Data
28
5 0.5 1.0 1.7 8.0 14.7 43.5 72.0
(13mm) (19mm) (25mm) (38mm) (51mm) (76mm) (102mm)
1/2" 3/4" 1.0" 1.5" 2.0" 3.0" 4.0"
00.78 0.1563 0.26112 1.699 2.8249 8.309 13.74283
0.9 0.9 1.2 -3.016 0.1435 0.227 0.23707
1.5 3 5 5 10 20 40
10 20 30 100 200 300 500
10 0.5 1.8 3.0 16.5 28.9 85.0 140.7
15 1.3 2.5 4.3 25.0 43.1 126.6 209.5
20 1.7 3.3 5.6 33.5 57.3 168.1 278.2
25 2.1 4.1 6.9 42.0 71.5 209.7 346.9
30 2.5 4.9 8.2 50.5 85.7 251.2 415.6
35 2.9 5.7 9.5 59.0 100.0 292.8 484.3
40 3.2 6.4 10.8 67.5 114.2 334.0 553.0
45 3.6 7.2 12.1 76.0 128.4 375.8 621.7
50 4.0 8.0 13.4 84.5 142.6 417.4 690.4
55 4.4 8.8 14.7 93.0 156.8 458.9 759.2
60 4.8 9.6 16.0 101.5 171.0 500.5 827.9
65 5.2 10.4 17.3 109.9 185.2 542.2 889.6
70 5.6 11.1 18.6 118.4 199.5 583.6 965.3
75 6.0 11.9 19.9 126.9 231.7 625.1 1034.0
80 6.4 12.7 21.3 135.4 227.9 666.7 1102.7
85 6.8 13.5 22.6 143.9 242.1 708.2 1171.4
90 7.1 14.3 23.9 152.4 256.3 749.7 1240.2
95 7.5 15.0 25.2 160.9 270.5 791.3 1308.9
100 7.9 15.8 26.5 169.4 284.7 832.8 1377.6
105 8.3 16.6 27.8 177.9 299.0 874.4 1446.3
110 8.7 17.4 29.1 186.4 313.2 915.9 1515.0
115 9.1 18.2 30.4 194.9 327.4 957.5 1583.7
120 9.5 18.9 31.7 203.4 341.6 999.0 1652.4
125 9.9 19.7 33.0 211.9 355.8 1040.6 1721.2
TFS-050 TFS-075 TFS-100 TFS-150 TFS-200 TFS-300 TFS-400
Sensor Model
Equivalent GPM *
Learned Flow
(PPS)
Size
K Value
Offset
Min. GPM
Max. GPM
