2
1 - Program Switch
Four-position slide switch used to select
program A, B, C and D for set up, review
and manual control.
2 - Digital Display
a - Station run time icon.
b - Start time icon.
c - Program identifiers.
d - Prompt displayed with Interval schedule
length
e - Flow sensor icon displayed with flow
sensor expansion module
f - % symbol displayed when the
Season Adjust function is active.
g - Water drop icon indicates current
watering activity. Icon with slash
indicates automatic operation is disabled
(Off, station disabled or Rain Delay
function.
h - Prompt displayed to indicate
current day within an Interval watering
day schedule.
i - Expansion module dock identifier
(I, II and III, left to right).
j - Hollow circles represent the station
terminals of an installed 4-or 8-station
expansion module. Station positions of
the current operating station or stations
assigned to a program are indicated by
a solid circle.
k - Indicates the station number or start
time number is currently shown in
the 2-digit numeric display (directly
above).
l - 2-digit display identifies the
station number or start time number
currently selected.
3 - Navigation Buttons
The and buttons are used to select
function menu items.
All numeric, On/Off, and Yes/No values
are selected with the and buttons.
4 - Function Dial
Turns in either direction to select the
following operating, control, and program-
ming functions:
run – The normal position for
automatic controller operations.
current time/day – To set clock time,
day and date.
station times – To set station
run time.
start times – To set program start
times.
calendar days – To set
program watering day schedule by days
of the week.
odd/even – To set program
watering day schedule by Odd or Even
numbered days.
season adjust – To adjust run time of all
stations within a program and/or program
within a month from 0 to 200% in 10%
increments.
special functions – To select special-
ized setup and programming options
(see page 10 for details).
sensors – To select flow sensor
operation setup parameters.
The following brief descriptions of the controller components and display elements are provided
for general overview. Each of these items are explained in detail within the appropriate section of
this guide.
