18
Introduction
TV front and side panel controls and connections
10 Program channels into the TV’s channel memory. See “Auto
Tuning” on page 46.
11 For details on using the TV’s features, see chapters 6 and 7.
12 For help, refer to “Troubleshooting” on page 114.
13 For technical specifications, see “Specifications” on page 120.
14 For the End User License Agreement, see “License
Agreement” on page 124.
TV front and side panel controls and connections
(Sample Illustration) Front and side panel controls and connections
1 Power On/Standby LED—Power indicator light (glows green
when the TV power is On).
2 Remote sensor (embedded)—Point the remote control toward
this remote sensor. Available on certain models.
3 POWER—Turns the TV On/Off. If the TV stops responding
to the buttons on the remote control or TV control panel and
you cannot turn off the TV, press and hold the POWER button
on the TV control panel for a few seconds to reset the TV.
4 CHANNEL / —When no menu is onscreen, these buttons
change the channel (programmed channels only, see “Storing
channels in memory (optional)” on page 46).
5 VOLUME buttons / —When no menu is onscreen, these
buttons adjust the volume level.
6 MENU—Accesses the on-screen menus. When a menu is
displayed, this button also functions as the ENTER button.
7 EXIT—Instantly closes an onscreen menu.
8 ARROWS /// —When a menu is onscreen, these
buttons function as up/down/left/right menu navigation
buttons.
TV front TV TopLeft side panel
1 2
3
8
9
4
6
7
5
10
